tesa® 4950 – LSE Filmic Mounting Tape (100 μm)

Transparent, Sustainable Mounting Tape for Low Surface Energy (LSE) Substrates

Product Overview

tesa® 4950 is a high-performance, double-sided transparent PET film tape specifically developed for reliable bonding on

low surface energy (LSE) materials such as PP, PE, and EPDM – without the need for primer. With a total thickness of

100 μm and a 12 μm PET backing containing 90% post-consumer recycled (PCR) content, it combines strong technical

performance with improved sustainability.

The tackified acrylic adhesive provides strong initial tack, excellent shear strength, and dependable performance under

demanding environmental conditions.

Sustainable Aspects

• 90% post-consumer recycled PET in the film backing.
• Responsibly sourced paper liner (certified).
• Supports more sustainable bonding solutions without compromising technical performance.

Key Features & Benefits

• LSE-optimised adhesion – bonds reliably to PP, PE, EPDM and other low surface energy substrates without primer.
• High shear strength – maintains secure bonds under mechanical stress and elevated temperatures.
• Dimensional stability – PET backing ensures clean handling and precise, stable die-cuts.
• Thermal resistance – withstands short-term exposure up to 200°C and long-term up to 100°C.
• Low VOC – tested according to VDA 278 for cleaner indoor air.
• UL certified – in accordance with UL 969 (UL file: MH 18055).
• Transparent construction – ideal where clean aesthetics and invisible bonding are important.

Typical Applications

• Versatile mounting solution for a wide range of demanding industrial applications.
• Primerless bonding to LSE substrates such as PP, PE, and EPDM.
• Long-term mounting of gaskets, seals, and molded components on hard-to-bond surfaces.
• Industrial assembly tasks where dimensional stability, transparent bonding, and clean edges are critical.

Technical Specifications

Construction

• Backing: Post-consumer recycled PET film
• Post-consumer recycled content (backing): 90%
• Adhesive: Tackified acrylic
• Total thickness: 100 μm
• Color (tape): Transparent
• Liner color: Brown with blue logo
• Liner thickness: 69 μm
• Liner weight: 80 g/m²

Performance & Resistance

• Elongation at break: 50%
• Tensile strength: 20 N/cm
• UV ageing resistance: Good
• Chemical resistance: Good
• Humidity resistance: Very good
• Softener resistance: Very good
• Static shear resistance at 23°C: Very good
• Static shear resistance at 40°C: Very good
• Static shear resistance at 70°C: Very good
• Tack: Very good
• Temperature resistance (long-term): 100°C
• Temperature resistance (short-term): 200°C
• Minimum temperature resistance: -40°C

Adhesion Values (initial)

Liner Variants

• PV04: White PE-coated paper liner (126 μm; 126 g/m²)
• PV20: Branded brown glassine paper liner (69 μm; 80 g/m²)

Additional Information

• Low VOC: Measured according to VDA 278 – tesa® 4950 does not contain any single substances restricted by the drafted GB regulations (China).

Disclaimer

All information is based on tesa® testing and practical experience. They are provided as typical values only and are not intended as a specification.

Users are responsible for verifying that tesa® 4950 is suitable for their specific application and process.
